MEDICAL SINGLE-SIDED AND DOUBLE-SIDED ADHESIVE TAPES
GERGONNE INDUSTRIE is a medical adhesive tape manufacturer and medical polyurethane film manufacturer.
The ADHECARE range regroups all standard references developed and manufactured by GERGONNE INDUSTRIE for the healthcare and medical sector.
The products in the ADHECARE range are used alone or in combination with other products, and they are used in the production of medical devices.
Our medical breathable PU films
Our high quality medical grade polyurethane films have the following features:
- Very breathable PU films: very high permeability to water vapor (high MVTR films)
- Barrier and watertight to shield wounds from the external environment
- Mat appearance and mechanical performance within market expectations
Polyurethane film – paper carrier
The paper carrier allows for direct coating of adhesive (acrylic, hydrocolloid or silicone) onto the medical PU film. It can be easily removed during the converting/cutting stage.
| Product | Film colour | Film thickness (µm) | Carrier thickness (µm) | MVTR (g/m²/24h) | |
|---|---|---|---|---|---|
| M324B15 | Transparent | 15 | 135 | 13 000 | Technical sheet |
| M329B15 | Skin colour | 15 | 135 | 13 000 | Technical sheet |
| M312B15 | Transparent | 15 | 120 | 13 000 | Technical sheet |
| M317B15 | Skin colour | 15 | 120 | 13 000 | Technical sheet |
| M324B30 | Transparent | 30 | 135 | 10 000 | Technical sheet |
| M329B30 | Skin colour | 30 | 135 | 10 000 | Technical sheet |
Polyurethane film – high temperature filmic carrier
The transparent filmic carrier allows to see through the product and thus facilitates the positioning of the finished product, by the medical staff.
The filmic carrier is resistant to high temperatures, allowing direct coating onto the film.
| Product | Film colour | Film thickness (µm) | Carrier thickness (µm) | MVTR (g/m²/24h) | |
|---|---|---|---|---|---|
| M381B15 | Transparent | 15 | 65 | 13 000 | Technical sheet |
| M386B15 | Skin colour | 15 | 65 | 13 000 | Not available |
| M381B30 | Transparent | 30 | 65 | 10 000 | Technical sheet |
| M386B30 | Skin colour | 30 | 65 | 10 000 | Not available |
Polyurethane film – specific products
Mainly designed for the manufacture of frame dressings.
| Product | Film colour | Film thickness (µm) | Carrier thickness (µm) | MVTR (g/m²/24h) | |
|---|---|---|---|---|---|
| M204 | Transparent | 20 | 105 | 10 000 | Technical sheet |
Our medical adhesive tapes
The Adhecare range also includes various medical adhesive tapes solutions to address different issues in the medical market, such as:
- Medical single-sided non-woven tape
- Medical single sided PU film tape
- Medical single sided micro perforated PE film tape
- Medical double-sided tape (one side for skin and one for plastics surfaces )
Single sided polyurethane film – paper carrier
Designed for manufacturing of medical devices, consumer plasters or advanced wound care products. Perfect for frame dressing applications.
| Product | Film colour | Film thickness (µm) | Carrier thickness (µm) | Adhesive coat weight (g/m²) | MVTR film + adhesive (g/m²/24h) | |
|---|---|---|---|---|---|---|
| M026 | Transparent | 20 | 105 | 20 | 800 | Technical sheet |
Single sided polyurethane film – filmic carrier
Designed for manufacturing of medical devices, standard post-operative dressings and surgical
drapes. The presence of the filmic carrier facilitates easy application of these highly flexible adhesive polyurethane films.
These are economical, high-performance adhesive solutions.
| Product | Film colour | Film thickness (µm) | Carrier thickness (µm) | Adhesive coat weight (g/m²) | MVTR (g/m²/24h) | |
|---|---|---|---|---|---|---|
| M011 | Transparent | 20 | 35 | 20 | 400 | Technical sheet |
| M025 | Transparent | 25 | 70 | 20 | 400 | Technical sheet |
Single sided polyester non-woven
Designed for manufacturing of medical devices, standard plasters or surgical dressings. These soft non-woven materials are known for being conformable.
| Product | Carrier colour | Carrier weight (g/m²) | Adhesive coat weight (g/m²) | MVTR (g/m²/24h) | |
|---|---|---|---|---|---|
| M010 | White | 50 | 40 | 1000 | Technical sheet |
| M037 | White | 45 | 30 | 1000 | Technical sheet |
| M041 | Skin colour | 50 | 30 | 1000 | Technical sheet |
Single sided polyethylene film
Designed for manufacturing of medical devices or standard plasters. Breathable microperforated PE film, water resistant.
| Product | Carrier colour | Perforation | Carrier weight (g/m²) | Adhesive coat weight (g/m²) | MVTR (g/m²/24h) | |
|---|---|---|---|---|---|---|
| M036 | Transparent | No | 65 | 30 | – | Technical sheet |
| M017 | Transparent | Yes | 65 | 30 | 4000 | Technical sheet |
| M018 | Skin colour | Yes | 65 | 30 | 4000 | Technical sheet |
| M019 | Blue | Yes | 65 | 30 | 4000 | Technical sheet |
Differential double sided polyester film
Suitable for the fixation of surgical drapes or medical devices requiring a good adhesion on all types of materials including low surface tension materials on the open side and attachment to the skin on the closed side.
*OS: Open Side / CS: Closed Side
| Product | Carrier colour | Carrier weight (g/m²) | Adhesive coat weight (g/m²) | OS adhesion (N/25mm) | |
|---|---|---|---|---|---|
| M015 | Transparent | 12 | OS 50 / CS 40 | On PP 10 / On ABS 20 | Technical sheet |
Double sided polyester non-woven
This medical tape is designed for the assembly or fixation of medical devices onto the skin. Very conformable.
| Product | Carrier colour | Carrier weight (g/m²) | Total adhesive coat weight (g/m²) | |
|---|---|---|---|---|
| M038 | White | 45 | 60 | Technical sheet |
Our silicone gel materials
As a manufacturer of silicone dressings, GERGONNE offers a range of materials coated with silicone gel for pain-free removal.
Depending on usage criteria and customer applications, we supply:
- Silicone non-woven (silicone gel bilaminate)
- Silicone PU film (unperforated or perforated silicone gel, silicone gel bilaminate and silicone gel trilaminate)
Double sided polyurethane film
Our double sided PU film are designed for manufacturing of medical devices and
particularly for the assembly of multilayer products, such as wound dressings.
Pain free and atraumatic removal.
Conformable and repositionable products.
The M029 reference is perforated, giving it breathable properties and allowing exudates to pass through.
| Product | Adhesive type 1 – adhesive coat weight (g/m²) | Carrier thickness (µm) | Adhesive type 2 – adhesive coat weight (g/m²) | Open surface | |
|---|---|---|---|---|---|
| M027 | Silicone gel – 150 | 30 | Acrylic – 40 | / | Technical sheet |
| M029 | Silicone gel – 150 | 30 | Acrylic – 40 | 30 % (size of holes: 2.6mm) | Technical sheet |
Single sided polyester non-woven
Designed for manufacturing of medical devices, standard or post-operative dressings with pain free and atraumatic removal.
| Product | Carrier colour | Carrier weight (g/m²) | Adhesive coat weight (g/m²) | |
|---|---|---|---|---|
| M020 | White | 60 | 120 | Technical sheet |
Single sided polyurethane film
Designed for manufacturing of medical devices, standard or post-operative dressings and skin protection products with pain free and atraumatic removal.
Ultra-thin and conformable solution.
| Product | Film thickness (µm) | Carrier thickness (µm) | Adhesive coat weight (g/m²) | MVTR (g/m²/24h) | |
|---|---|---|---|---|---|
| M021 | 20 | 60 | 60 | 1100 | Technical sheet |
| M032 | 20 | 105 | 60 | 1000 | Technical sheet |
